Front Toe Adjustment

Fig. 2 Adjusting Toe:

Toe-out is controlled by tie rod position. Adjustment is made by loosening the clamp bolts at the steering knuckle end of the tie rods and rotating the rods to obtain proper toe setting, Fig. 2. After correct toe setting is obtained, tighten clamp bolts. Torque clamp bolts to 41 ft. lbs.
