Neutral Switch




1. Disconnect the battery negative cable.
2. Disconnect the neutral switch connector.
3. Remove the neutral switch.
4. Install the reverse order of removal.

Tightening torque : 20 - 29 N.m {2.0 - 3.0 kgf.m, 15 - 21 ft.lbf}
