Control Module: Service and Repair

Replacement
1. Disconnect the negative battery cable.
2. Remove the front side trim (passenger side).




3. Remove the powertrain control module engine.




4. Remove the nuts shown in the figure and disconnect the powertrain control module (transmission) connectors.
5. Install the new powertrain control module (transmission).

Tightening Torque: 7.9-10.7 Nm (70-95 in.lb.)

6. Connect the powertrain control module (transmission) connectors.
7. Install the powertrain control module engine.

Tightening Torque: 7.9-10.7 Nm (70-95 in.lb.)

8. Install the front side trim (passenger side).
9. Connect the negative battery cable.
