Cruise Control Switch: Service and Repair

Cruise Control Main Switch

Removal

1. Disconnect the battery ground cable.
2. Remove the meter cluster assembly (1).
- Refer to Instrument Panel Assembly in Body Structure section.




3. Remove the cruise control main switch (2).
- Disconnect the switch connector.
- Push the lock from the back side of the instrument panel cluster assembly.

Installation
To install, follow the removal steps in the reverse order.
