Spark Plug: Testing and Inspection

On-vehicle Inspection

Inspect Spark Plug
1. Inspect the electrodes(A) an ceramic insulator(B).




Inspection Of Electrodes





2. Check the electrode gap (A).

Standard : 1.0 - 1.1 mm (0.0394 - 0.0433 in.)
