Compressor Clutch Relay: Service and Repair

Compressor Relay Replacement

Removal Procedure





1. Remove the cover from the underhood convenience center (1).
2. Remove the A/C compressor relay (1) from the convenience center (2).



Installation Procedure





1. Install the A/C compressor relay (1) to the convenience center (2).
2. Install the cover to the underhood convenience center (1).
