GMC
>>
1994
>>
Yukon V8-350 5.7L
>>
Repair and Diagnosis
>>
Locations
>>
Component Locations
>>
Modules
>>
Knock Sensor Module
Knock Sensor Module
Engine Wiring, RH Side View:
Above RH rocker cover.
