System Specifications

SPECIFICATIONS














FLYWHEEL TORQUE

NOTE: New flywheel/flexplate bolts must be used.





1. Install the spacer and new flywheel/flexplate bolts (1). Tighten bolts to 45 Nm (33 ft. lbs.)
2. Rotate the flywheel/flexplate bolts an additional 90° clockwise.
