Distributor Cap: Service and Repair

Remove or Disconnect:
1. Remove distributor from engine. Refer to DISTRIBUTOR REPLACEMENT.

Distributor Removal:

2. Remove four cap attaching screws from distributor assembly.

Install or Connect:
1. Install cap onto distributor
2. Tighten attaching screws
Torque Value: 2.8 N-m (25 lb.in.)
