Ignition System: Testing and Inspection
Diagnostics for Engine Starting FailureIGNITION CONTROL SYSTEM
CAUTION: After servicing or replacing faulty parts, perform Clear Memory Mode Clear Memory Mode, and Inspection Mode Inspection Mode.
WIRING DIAGRAM:
